Molten Salt Oxidation Test Unit for Resin
A technical test unit for resin reaction in high-temperature molten salt, supporting precise feed control, molten-salt reaction regulation, stable product discharge and off-gas treatment for process research and pilot validation.
Product Overview
▅ Core Technical Advantages
Precise feed control: A quantitative resin particle feeder and gas mass flow controllers provide dual-channel control of reactant feed and dry air or nitrogen flow. Reactant feed accuracy reaches ±0.5%, and gas media can be switched quickly for different reaction atmospheres.
Controllable high-temperature reaction process: An electrically heated molten-salt furnace and multi-point temperature measurement system support continuous reaction-temperature adjustment from 300-800°C with ±2°C control accuracy. Stirring and pressure-balancing modules help maintain stable, repeatable test conditions.
Safe and stable product discharge: An anti-blocking discharge mechanism and cooling jacket rapidly cool high-temperature reaction products and support continuous or intermittent discharge, reducing the risk of molten-salt solidification and pipeline blockage.
Efficient off-gas purification: A three-stage off-gas treatment system combining cyclone separation, activated-carbon adsorption and cooling condensation captures molten-salt mist and organic volatiles, helping treated off-gas meet laboratory emission requirements.
Flexible test-parameter adaptation: Core parameters including reactant feed rate, reaction temperature and gas flow can be adjusted over a wide range. The unit supports rapid switching among resin types and molten-salt systems for multi-variable process research.
Intelligent test monitoring: A touch-screen control system displays and records feed rate, reaction temperature, pressure and off-gas treatment status in real time. Data export and trend analysis support reaction-process optimization.
▅ Key Technical Parameters
Reaction temperature range: 300-800°C
Temperature control accuracy: ±2°C
Resin feed rate: 5-500 g/h, accuracy ±0.5%
Gas flow: 1-10 L/min
Applicable gases: dry air and nitrogen
Discharge mode: continuous / intermittent optional
Applicable materials: resin reactants and molten-salt media
Core functions: feed control, high-temperature reaction regulation, product discharge and off-gas treatment
Typical applications: university chemical laboratories, new-material R&D centers and enterprise molten-salt reaction pilot workshops
▅ Application Value
The unit provides a controllable test environment for high-temperature molten-salt resin reactions. Wide parameter adjustment, precise process control and safe off-gas treatment help shorten process-development cycles and reduce pilot-stage risk and cost.
